FEEDING HEAD : Servo Auger screw filler
PACKING RANGE : 10 to 100 grams
PRODUCTION SPEED : 40-60 pouches/min
MACHINE CONTROL SYSTEM : PLC with Touch Screen
FILM WIDTH : UPTO 240mm
FILM THICKNESS : 60-100microns
FILM MATERIAL : Laminated
SEALER HEATING SYSTEM : Continuous
FILLING ACCURACY : +/- 1% (Depends on product)
INNER CORE DIA. OF FILM ROLL : 70mm
OUTER DIA. OF THE FILM ROLL : upto 300
POUCH STYLE : Side Seal type
POUCH WIDTH : up to 110mm
POUCH LENGTH : up to 120mm
COMPRESSED AIR PRESSURE : 5KG
AIR CONSUMPTION : 30m/Hour
POWER CONSUMPTION : 5KW
PEAK POWER : 5KW
POWER REQUIREMENT : 3KVA, single phase220 V,50Hz
FILM GUARD MECHANISM : Auto Stop when film is exhausted
POUCH COUNTER : Provided
DATE PRINTING DEVICE : 5-6weeks
PHOTO CELL : Provided
MACHINE DIMENSIONS IN ‘MM’ : 750(W)X1100(D)X1650(H)approx
NET WEIGHT : 550kgs
